Albums Archives: Single & Multi dwelling residential Units

You are here:
  1. Home
  2. Photo Album
Basement HVAC
Ground Floor HVACExploded Axonometric HVACBasement HVAC

A 2,300 Sqft Residential Project in Toronto, ON

HVAC system with two furnace/AC

Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 31, 2022
Snow melting plan for ground floor
Basement HVAC 3D PlanExploded Axonometric HVACSnow melting plan for ground floor

A 3,700 Sqft Residential Project in Thornhill Ave, ON

HVAC System WIth multi furnaces/ ACs, heated floor garage & snow melting for front porch and driveway

Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 28, 2022
Second Floor HVAC 3D plan
Hvac-planGarage-exhaust-systemSecond Floor HVAC 3D plan

A 6,700 Sqft Residential Project in Toronto, ON

HVAC system with four furnace/AC systems and garage exhaust system with make-up air fan & heater

Residential Pojects, Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 28, 2022
Basement HVAC 3D plan
Second Floor HVAC 3D planExploded Axonometric HVAC 3D planBasement HVAC 3D plan

A 5,500 Sqft Residential Project in North York, ON

HVAC system with two furnace/AC

Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 28, 2022
3D HVAC plan second floor
Exploded Axonometric HVAC 3D plan3D HVAC plan for basement3D HVAC plan second floor

A 6,300 Sqft Residential Project in Norwich, ON

HVAC system with three furnaces/AC

Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 28, 2022
Second Floor HVAC
Exploded Axonometric HVACBasement HVAC planSecond Floor HVAC

A 13,400 Sqft Residential Project in North York, ON



Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 27, 2022
Basement -Floor Heating-min
HVAC plan basementGround Floor -Floor Heating-minBasement -Floor Heating-min

A 3,800 Sqft Residential Project in Mississauga, ON

In-floor heating as for the primary heating system & ductless heat pump for Cooling and supplementary heating

Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 27, 2022
Ground Floor - Floor Heating
Exploded Axonometric HVACBasement - Floor HeatingGround Floor - Floor Heating

An 8,900 Sqft Residential Project in Richmond Hill, ON

 Multi HVAC systems with modulating furnace/ ACs for primary heating, In-floor hydronic for basement & indoor pool complete with de-humidification and snow melting for the outdoor pool, sidewalks & driveway

Single & Multi dwelling residential UnitsBy Thermond EngineeringJanuary 26, 2022
Mechanical & Electrical design for a pool in a House
Plumbing-PlanHvac-PlanMechanical & Electrical design for a pool in a House

A Residential Project in Richmond Hill, ON

HVAC design with ducted heat Pump, complete plumbing for domestic water & sanitary & electrical basic design

Residential Pojects, Single & Multi dwelling residential UnitsBy Thermond EngineeringNovember 13, 2019
HVAC-Pool-design
Basement HVAC 3D PlanExploded Axonometric HVAC 3D planHVAC-Pool-design

A Residential Swimming Pool Project in Markham, ON

HVAC design with four furnace/AC , Pool HVAC design with air handler & dehumidifier

Residential Pojects, Single & Multi dwelling residential UnitsBy Thermond EngineeringNovember 13, 2019
12
